Easy bolt-on installation Increased ground clearance Levels the front with the rear of the vehicle Lower control arms provide proper offset to allow for wider tires. Kit maintains stock alignment for precise high speed handling and proper caster/pinion alignment.
Rear shock relocation keeps shocks clear from the tires. X-Flex control arm features: Flex joints feature a massive 2.5 Inch diameter body and 1.25 inch thread. Fully greasable. Lower joints pivot up to 35 degrees.
Features:
- Easy bolt-on installation
- Increased ground clearance
- Levels the front with the rear of the vehicle
- Lower control arms provide proper offset to allow for wider tires.
- Kit maintains stock alignment for precise high speed handling and proper caster/pinion alignment.
- Rear shock relocation keeps shocks clear from the tires.
- X-Flex control arm features: Flex joints feature a massive 2.5 Inch diameter body and 1.25 inch thread.
- Fully greasable.
- Lower joints pivot up to 35 degrees.
Notes: Does Not fit AWD models. Models equipped with a CV style front driveshaft may result in driveshaft vibration. If this occurs, replacing the driveshaft, axle yoke and, or transfer case yoke will need to be performed to rid the vehicle of driveline vibration. CV Driveshaft Example
Details:
- Sold As Kit
- Drive 4WD
- Lift Height 4.0 inch
- Mount Style Bolt On
- Front Components Lifted coil springs Adjustable lower control arms Sway-bar quick disconnects Adjustable track bar Bumpstop extensions Transmission crossmember spacers Hardware
- Rear Components Lifted coil springs Upper control arm bracket Sway-bar brackets Bumpstop extensions Shock relocation kit Hardware
